Your Professional Photovoltaic Automatic Tracking Bracket Supplier

Qingdao Jiudingli Steel Structure Engineering Co., Ltd.It's founded in 2003 ,loated in Qingdao .The company is 5km from airport. And mainly engaged in the production and manufacturing of solar bracket ,transmission line towers,substation steel structures,communication towers etc.The company have production license of 500KV and 750KV transmission line tower.

Durable Solar Panel Mounting Brackets
used to fix and support solar panels, ensuring their stable operation under various environmental conditions and maximizing power generation efficiency.
Ground Mounted Solar Structure
high power generation efficiency, easy maintenance, and scalable deployment
Dual Axis Solar Tracking System
The two-axis tracking photovoltaic bracket is a photovoltaic bracket system with two rotating axes, which can track the sun at the same time in the sun's azimuth and height Angle
Photovoltaic Solar Tracking System
The structure is made of hot-dip galvanized steel plate or new galvanized aluminum-magnesium alloy, which has high strength and good corrosion resistance and can be installed in coastal areas.
RP Flat Single Axis Solar Tracking System
Modular design, simple structure, low cost, fast and convenient installation, can adapt to double-sided components, independent drive or small linkage structure, flexible combination
PT Tilted Single Axis Solar Tracking System
RT Tilted Single Axis Solar Tracking System (RT Tilted Single axis solar tracking System) is a system that automatically adjusts the Angle of photovoltaic modules to track the movement of the sun.
Solar Panel Dual Axis Tracking System
The advantage of the two-axis tracking photovoltaic bracket is that it can achieve more accurate tracking and improve the efficiency of the photovoltaic system.
Solar Panel Track System
Azimuth tracking range ±45°/±55°. Tilted elevation angle 10°-30°. Tracking accuracy 0.1°-2° (Adjustable).
Solar PV Tracking System
Mounting Type:Solar PV Tracking SystemSurface Treatment:Hot Dip GalvanizedInstallation Site:Solar Energy StationFeature:Quick InstallationApplicable Area:Flat Land,Gentle Slope,Marsh,FarmTilt

Why Choose us

Complete Product Qualifications

The company holds Grade II Steel Structure Professional Contracting Qualification. Additionally, the company has obtained ISO 9001, ISO 14001, ISO 45001, and CE certifications.

Strong Technical Strength

The company employs 26 professional personnel with diverse technical and economic qualifications. It provides efficient OEM and ODM services, with an annual production capacity reaching up to 360,000 tons.

Advanced Production Equipment

The company is equipped with advanced machinery, including CNC cutting machines, three-roll hydraulic plate rolling machines, hydraulic plate shearing machines, edge planers, end milling machines, and automatic sandblasting facilities.

Parameter

mounting type	Ground solar mounting system
application	Pv solar panel installation
material	Magnesium aluminum zinc
	Pre galvanized steel
	Ht dipped galvanized carbon
	Aluminum alloy
surface treatment	Andoized hot dip galvanized
installation site	Solar energy station
feature	Quick installation
certificate	Ce/ISO9001
standard	International standards
applicable area	Flat land,gentile slope,marsh,farm
tilt angle	0-70°
life	25years
pile foundation form	Driven pile/cast-in-place pile/cement foundation/screw pile
service	Professional customization service

Customization Process

Communication Needs: Custom colors can be tailored to meet specific customer requirements. Please provide your customization concepts and detailed specifications for further discussion.

Production Execution: Following the confirmed design, we implement meticulous production processes with strict quality control at every stage, ensuring consistency and precision before proceeding to mass production.

Quality Inspection and Packaging: Upon completion of the product, a comprehensive three-stage inspection process is conducted to ensure quality standards are met. Subsequently, the products are packaged in accordance with your specified requirements.

Delivery Assurance: We ensure timely delivery of the products within the agreed timeframe as per the contract terms.

Types of Photovoltaic Automatic Tracking Bracket

The photovoltaic automatic tracking bracket produced by our company mainly include the following types:

Dual Axis Solar Tracking System

The two-axis tracking photovoltaic bracket is a photovoltaic bracket system with two rotating axes, which can track the sun at the same time in the sun's azimuth and height Angle

RP Flat Single Axis Solar Tracking System

Modular design, simple structure, low cost, fast and convenient installation, can adapt to double-sided components, independent drive or small linkage structure, flexible combination

PT Tilted Single Axis Solar Tracking System

RT Tilted Single Axis Solar Tracking System (RT Tilted Single axis solar tracking System) is a system that automatically adjusts the Angle of photovoltaic modules to track the movement of the sun.

Solar Panel Track System

The Solar Panel Track System is a device used in solar power generation systems. It automatically adjusts the angle of the solar panels to ensure that the panels are always facing the sun, thereby maximizing light absorption and improving power generation efficiency.

Benefits of Photovoltaic Automatic Tracking Bracket

Independent Drive System
The system adopts a 2-3 row linkage or independent drive design, which can support multiple panels to be adjusted simultaneously or independently, improving the reliability and flexibility of the system.

Wide Range Of Applications
The system can be installed in different terrain conditions such as flat land, gentle slopes, swamps and farms. It has strong adaptability and is suitable for a variety of application scenarios.

Accurate Tracking Capability
The tracking accuracy of the system is adjustable, ranging from 0.1°-2°, which can accurately track the movement of the sun to ensure that the solar panels are always facing the best angle, thereby improving power generation efficiency.

Strong Wind Resistance
The system can withstand the impact of a maximum wind speed of 40m/s, which is very suitable for use in areas with strong winds, increasing the safety and stability of the system.

Adapt To A Variety Of Installation Methods
Support a variety of pile foundation forms (driven piles, cast-in-place piles, cement foundations, screw piles), making the installation more flexible, and the most suitable installation method can be selected according to different geological conditions.

Delivery Information

Shipping Methods

We offer a variety of shipping options, including sea freight, railway transportation, and international express delivery, to meet the diverse needs of our customers.

Estimated Delivery Time

We will provide you with the estimated delivery time for your order, which will be clearly stated in the formal order to ensure your rights are protected, allowing you to arrange for the receipt of your goods in a timely manner.

Order Tracking

We provide order tracking services, allowing you to stay informed about the current status and expected arrival time of your order. Detailed inspection information and shipping manifests, including photos and videos, are provided to ensure the security of your transactions.

Certificate

FAQ

Q: What is the conclusion of dual axis solar tracking system?

A: Conclusion can be made that dual-axis solar tracker is more efficient than fixed or static solar systems and single axis solar tracker in terms of the electrical energy output .

Q: Which motor is used in dual axis solar tracking system?

A: Two geared stepper motors are used to move the solar panel so that sun's beam is able to remain aligned with the solar panel.

Q: What is the working principle of solar tracking system?

A: Active solar tracking system is the system that determines the position of the sun path in the sky during the day with the sensors. These sensors trigger the motor or actuator to move the drive system to the system towards the sun throughout the day.

We're well-known as one of the leading photovoltaic automatic tracking bracket manufacturers and suppliers in China. If you're going to buy photovoltaic automatic tracking bracket made in China, welcome to get quotation and specification from our factory. For price consultation, contact us.
